What Is a Draft Inducer Motor? A draft inducer motor is a positive pressure blower that activates when you need heat distributed throughout your home. It works like this: Air is blown into the vent for about 30 seconds before the heating cycle begins.

What are the symptoms of a bad inducer motor?

One of the first indications of a bad draft inducer motor is likely to be the sound it makes. A failing inducer motor may create a noise shortly after a heating cycle begins. This could be a tapping noise, or a humming or whirring sound.

How long does a draft inducer motor last?

A: On average, you can expect a well-built inducer motor to last around 20 years.

Is the inducer motor the same as a blower motor?

The inducer motor continues spinning to provide the burners with a steady flow of oxygen. The draft created by the motor also prevents soot from clogging the furnace’s burners. … In essence, the draft inducer motor is nothing more than blower motor, fan, and electrical box.

What causes an inducer motor to fail?

Most inducer motors failures are simply attributed to the older age of the furnace. In most cases, the internal bearings wear out and since the unit is a sealed unit, there is no way to repair the original motor. Instead the unit is simply replaced with a new one.

What is an induced draft blower?

Fans that are used to evacuate a space or create negative air pressure in a system are referred to as induced draft fans. … The induced draft fans used in combustion systems are normally high temperature and extra heavy-duty construction.

What does an inducer motor do on a gas furnace?

The draft inducer motor was introduced when the government mandated efficiency standards for furnaces. The purpose of the inducer motor is to move air and gasses out of the furnace and up through the heating vents. This determines how much and how fast air will flow through the heat exchanger.

What does an inducer motor cost?

A replacement draft inducer motor will cost between $500 and $700.

What happens when furnace inducer motor goes out?

When an inducer goes bad, it will be hot to the touch after trying several times to start the furnace. If the motor remains cool, your problem is most likely in one of the peripherals attached to the motor or in the electrical parts that drive its operation.

How much does it cost to replace an inducer motor?

Average Draft Inducer Motor Replacement Cost The average furnace inducer motor cost is around $245, when the part is under warranty and you pay only the labor to have it installed. The replacement cost is $465 when the warranty has expired and you pay for the furnace inducer motor.

Article first time published on

How much does a furnace cost for a 1500 square foot house?

For example, a 700- to 1,500-square-foot home will require a BTU rating between 40,000 and 60,000, which will cost between $2,000 and $3,000. A furnace for a home ranging in size from 2,000 and 5,000 square feet will need between 125,000 and 150,000 BTUs and will cost in the neighborhood of $3,300 to $6,500.

Where is the inducer motor on a furnace?

A draft inducer is a fan that’s located inside of your furnace near the heat exchanger. When your furnace begins a heating cycle, the draft inducer is one of the first devices that turns on.

Are inducer motors loud?

A draft inducer (or vent blower) is the most common problem on a gas furnace or boiler to cause a noticeable noise. … The small motor mounted within the housing can begin to make noise when there is buildup on the wheel (such as sulfur or creosote) or when the motor is close to the end of its usable life.

What is the purpose of the inducer motor and what switch closes after it starts?

When the inducer motor is running it creates small vacuum inside the furnace combustion chamber which makes sure all toxic gases are vented. For safety, a pressure switch is used to tell if the inducer motor has turned on. It does this by sensing the vacuum that the inducer motor creates and closes a switch.

What is draft in furnace?

Furnace draft, or negative pres- sure, is created in fuel-fired furnaces when high temperature gases are discharged at a level higher than the furnace open- ings. This is commonly known as the chimney effect. … This negative pressure causes ambient air to leak into the furnace.

What does an inducer do?

In molecular biology, an inducer is a molecule that regulates gene expression. … The gene is expressed because an inducer binds to the repressor. The binding of the inducer to the repressor prevents the repressor from binding to the operator. RNA polymerase can then begin to transcribe operon genes.

How do you lubricate a furnace draft inducer blower?

Spray a thin film of silicone lubricant on the motor shaft where it enters the blower wheel bearings. Reinstall the service panel, then turn on the circuit breaker to power the furnace.

What does induced draft mean?

Definition of induced draft : a draft produced by a suction steam jet or fan on the stack side of a furnace.

What is difference between induced draft and forced draft?

Forced-draft fans focus the pressure and volume at the outlet of the fan to push air through a system, creating positive air pressure. Industrial induced draft fans operate by focusing the pressure and volume at the inlet of the fan to pull air through a system.

What is the use of induced draft fan?

An induced draught fan (ID fan) is provided to maintain a negative pressure in the furnace by sucking the products of combustion from it with a slight positive pressure at the discharge end vis-à-vis the bottom of the chimney/stack.

How long should a furnace last?

A well-maintained furnace can last at least 15 to 20 years, but completing annual maintenance and being diligent with repairs can extend its life even longer.

Can a furnace be too big for a house?

Having a furnace that’s too big for your space is extremely inefficient. There are two simple signs that indicate that your furnace is most likely oversized: Your furnace runs for a short period of time before shutting off. Your home has uncomfortable hot and cold rooms.

Why is furnace installation so expensive?

HVAC installation is quite expensive, probably because it has emerged to be an immensely specialized trade. Owing to controlling humidity, thermodynamics, airflow, refrigerant, electrical, and plumbing, it is now high on demand.

Should I replace my 25 year old furnace?

Age of your Furnace If your furnace is pushing 25 years or more, it’s probably nearing the end of it’s effective lifespan. … You might choose to replace a 15 year old furnace, or it could last more than 30 years.

Can you run a furnace without a pressure switch?

Without the pressure switch, there is the potential for exhaust gases to fill the living space if the furnace malfunctions. A pressure switch that fails to turn on could be caused by a number of problems, including: Failure of the draft inducer motor. Restricted intake air vent.

Can you jump out a pressure switch on a furnace?

All you need is a little jumper wire (or regular wire will work, too). You likely have a normally open switch, and when you jump it, you are closing it. … If there seem to be no problems, then you can reasonably conclude that you need a new furnace pressure switch.

Is my furnace pressure switch bad?

If the pressure switch closes normally, the rest of the furnace sequence of operation will continue. If the pressure switch won’t close, the system will go into safety mode, try a couple more times, and eventually just start blowing cold air in your room, letting you know something is wrong with your furnace.

Will a cracked heat exchanger symptoms?

If you have a crack in the heat exchanger, you are likely to hear a rattling noise as your thermostat turns on the heat. Because the heat exchanger is made out of metal, as it is heated cracks will expand/contract, and can cause rattling, popping, and/or banging noises. Presence of Carbon Monoxide.
