According to CBMQ.com, it should be at least 24-gauge sheet metal or thicker — the lower the gauge, the thicker the metal. Typical code requires that single-wall stove pipe maintain at least an 18-inch clearance from any combustible material.

What kind of pipe do you use for a wood burning stove?

Class A chimney pipe is used for wood-burning fireplaces and stoves. It is also used when transitioning stove pipe through a wall or ceiling. It is often referred to as double-wall, triple-wall, all-fuel or insulated chimney pipe.

What is standard stove pipe size?

The two common sizes for round stove pipe in the US is 6″ and 8″. If you can detach your stove pipe from your collar you can just measure the diameter of the opening.

How do I choose a stove pipe size?

As a general rule, the diameter of the chimney should match the flue collar on your wood stove. A 6-inch stove requires a 6-inch flue. In most cases, a step up is also fine. For example, you could vent a 6-inch stove into an insulated chimney that is 8 inches in diameter.

What is the 2 10 rule?

If you are farther than 10′ away from the peak, your chimney needs to be 2′ above the highest point within 10′. For example, your chimney is exiting 20′ away from the peak and you have a 6/12 pitch roof.

How hot does double wall chimney pipe Get?

These pipes only need a 2-inch clearance to combustibles because they remain cool on the outside, while their internal design allows them to withstand temperatures as high as 1,700 or 2,100 degrees Fahrenheit for a limited time.

Can you use double wall stove pipe outside?

To do this requires that the pipe remain cool on the outside by having an internal design that creates a fire-safe venting system. … The goal is to minimize the outside diameter of the pipe and the allowable distance from combustibles. This can be 2 inches for double-wall pipe and 1 ½ inches for triple-wall pipe.

Should I use single or double wall stove pipe?

It is always recommended that you use double-wall pipe in a mobile home. The reason why you must use double-wall pipe for a clearance of 18″ or under is because it is air insulated. The outside of the double-wall pipe does not radiate heat like single-wall does.

Is 4 inch pipe enough for chimney?

It is suitable only if your chimney exhaust size is 4 inches. Similar type Flexible Duct offers a flexible 4-inch pipe specially designed for kitchen chimneys. Its pipe size is Diameter is 4.3 Inches, Length 3.3 Feet and Expanded Up To 10 Feet (L x B x H).

What is the standard chimney flue size?

Flue tile should be at least 5/8-inch thick. It is available in several sizes. The most commonly used sizes in residential construction are 8 by 8 inches, 8 by 13, and 13 by 13 (outside dimensions).

Article first time published on

What's the difference between stove pipe and chimney pipe?

What is the difference between stove pipe and chimney pipe? Many confuse the terms. Stove pipe is usually painted black and is used in the interior on the home until you transition through a wall or ceiling then class A chimney pipe is used thereon. Stove pipe, black pipe, single wall pipe all refer to the same thing.

Can I use B vent for a wood stove?

No can do. A stove like the Lange is rated same as other woodstove, for continuous 1000 F. B vent is aluminum, which would melt very quickly at the 1400, 1700 and 2100 test temperatures of the chimney needed for you unit.

How do I know what size flue I need?

The ideal flue size is typically determined by the exhaust outlet of the stove or appliance. The rule of thumb for sizing a chimney liner is that you never want it to be smaller than the appliance exhaust hole and you don’t want the liner to be three times the area of the exhaust hole of the appliance.

How far does chimney have to be from roof?

Tip. Generally speaking, a chimney or other exhaust vent should be 3 feet above the roof, or 2 feet above any other part of the roof that sticks up within a 10-foot radius of the chimney.

What is code for chimney?

This rule means that your chimney’s shortest side needs to be at least 3 feet above the roof penetration, and its top has to be 2 feet higher than any part of the building that’s within 10 feet.

Is a taller chimney better?

It is often better to make the chimney taller to avoid wind turbulence. A good objective is to have the top of chimney above the roof peak, and this is much easier if the chimney penetrates the roof near the peak.

Can you pipe a wood stove out the side of your house?

Venting to an Outside Wall Because a stovepipe or chimney on an outside wall cannot eliminate the stack effect, placing your stove there can also result in a cold hearth and a less efficient wood-burning appliance.

Can you run single wall stove pipe outside?

Just did some quick research and it turns out that both single- and double-walled stovepipe are only permitted indoors. When you transition to the outside through an insulated thimble you must use “Class A Chimney”, which is an insulated product.

Can wood stove pipe through wall?

If you’re setting up a wood-burning stove or pellet stove, running the chimney pipe through an outside wall saves the time and costs of installing a vertical chimney that requires a ceiling collar and roof flashing. … For brick or stone walls, enlist a professional to cut the holes.

How hot does black stove pipe get?

For safety reasons, UL specifies that manufactured chimneys must be able to sustain a continuous flue gas temperature of 1000ºF. That would correspond to about a 500-600º external temp on single-wall black stove pipe.

What temperature is too hot for a wood stove?

How hot is too hot when it comes to wood fire stoves and fireplaces? Anything over 800°F is starting to get too hot and could damage your wood stove or fireplace.

Which pipe is best for chimney?

You can use the plastic Chimney pipe during installation but it is not recommended to do so. The plastic pipes develop holes after a few months due to the hot air passing through them. So, it’s better to go with the aluminum pipe which is more long-lasting than the plastic ones.

What should be the height of chimney from gas stove?

If you have an electric stove then the optimal height of your chimney must be 60-80cm (25-30 inches). For gas stoves, the ideal height of the chimney must be around 45-60cm (18-24 inches). To know the accurate measurement of the height, do refer to the manual of your chimney.

What is the size of kitchen chimney?

Most kitchen chimneys are available in standard sizes of 60 cm and 90 cm. Choose the size of the chimney depending on the size of the stove and the size of the kitchen.

Does wood stove need double wall pipe?

You have to use double walled pipe when going through walls and floors and what not because the double wall and the space between the pipes cools enough that it can come in contact with wall materials. Single walled pipe would get hot enough to ignite the surrounding materials.

What is the purpose of double wall stove pipe?

Double wall stove pipe has superior insulation with 1/4″ airspace between the inner and outer pipe walls. This allows hotter flue gas temperatures improving draft meaning: Less chance of moisture or soot buildup within the vent. Less “smoking” of the stove at startup.

Can a flue be too big?

When a flue is too big, the chimney can be too cold. Cold chimneys make keeping a fire lit more difficult. They also lead to condensation and possible mold inside the chimney brickwork. They key to making and keeping a great draft in your fireplace is making sure the proper sized flue is installed.

What size flue do I need for a wood stove?

Under the Building Regulations, the minimum flue liner size you can use is 6 inches (150mm). But there are exceptions to this rule. You can use a 5-inch (125mm) flue liner with a stove that has a 5-inch if either of the following apply: You will only be burning smokeless fuel.

Are chimney caps standard size?

With masonry (at least here in the Kansas City Metro) the common sizes are 8 by 8, 8 by 13, 13 by 13, 8 by 17, and 13 by 17. Now they do make one size caps that fit all but they do not work properly, they’re a poor fit. My suggestion: get someone at the top of your chimney that knows how to measure for chimney caps.

Can you use single wall and double wall stove pipe together?

single wall pipe should fit into double wall without an adapter. … Double wall insulated requires an adapter with a screw-on end to fit the insulated pipe.

Can you use single wall stove pipe inside?

Use Single Wall Black Stove Pipe from your stove to a thimble or ceiling transition box, never inside a combustible wall or inside a chimney chase. An 18 inch clearance to combustibles is required and these pipes feature an unheard of fume-free finish.
